Gearbox Bearing & Seal Kit for Kubota RCK72P-28Z / RCK72P-F36 / RCK72R-F36

Bearing and seal service kit · 16 pieces

Includes bearings, oil seals, shims and hardware. Gears, shafts, gearbox housing and oil are not included.

Save $ 11.70 Save $ 11.70
Original price $ 194.97
Original price $ 194.97 - Original price $ 194.97
Original price $ 194.97
Current price $ 183.27
$ 183.27 - $ 183.27
Current price $ 183.27
Aftermarket replacement part

Direct buying discount applied. Prices on our site are lower than our marketplace listings to reflect the absence of third-party platform fees.

The crossed-out price is our current listing for this item on those marketplaces — not a former flipmfg.com price.

For servicing gearbox assemblies:

  • 7C765-51260
  • 04612-00220
  • 70712-33570
  • K5761-33540
  • 05712-00728
  • 76535-33440
  • 04611-00520
  • 08101-06205
  • K5671-33342
  • 04015-50100
  • 01133-51025
  • 63313-32270
  • 36330-28410
  • K5687-33550
  • 70712-33550

Will this fit your machine?

Start with the model on your mower deck’s ID tag. Enter it below, then check the serial number and original part numbers against Product details. Your tractor model alone won’t confirm fit.

Not included: 08101-06304. If your gearbox needs this part, obtain it separately.

F3710: Check the serial limit below. The later K5684-33540 key is not included. F2510/F2510E versions need a separate fitment check.

Listed applications — check the part details below (13)

Not sure? Start a guided fitment text to 903-320-4519 — we'll verify for free.

Mention part 707734 in your text so we know which one you mean.

Availability:
in stock, ready to be shipped
Free standard shipping · contiguous U.S.
Estimated standard delivery: See delivery information at checkout

Our standard 3–7 business-day transit estimate applies to in-stock items after dispatch.

Delivery details

Standard shipping is free within the contiguous U.S. The estimated delivery range uses our standard 3–7 business-day transit time after dispatch, with weekends and U.S. postal holidays excluded. Delivery varies by destination. It is not a guaranteed delivery date.

Need it sooner? Expedited options and prices are available at checkout. Shipping policy

Shipments to Canada require additional shipping costs with extended delivery times.

Top Quality Store on Google View details
60-day returns Prepaid label — no restocking fee
Secure checkout Major cards, PayPal, Apple Pay, and Shop Pay

Before you order

Find the right fit.

Start with your equipment tag and the original part number. If you’d like a hand, send us a photo and we’ll help.

Part information

Product details.

See what comes with this part and the details that help you choose the right version.

Aftermarket gearbox bearing, seal and service hardware kit for the listed Kubota mower deck configurations. FLIP 707734. Gearbox family reference K5677-33104 identifies the serviced assembly; this kit does not replace that complete assembly.

What’s included

Bearing, seal and service hardware kit; exact supplied parts and quantities are listed below.

Gears, shafts, housing and lubricant are not included. This is a selective service kit, not a complete gearbox or every part needed for an overhaul.

FLIP part
707734
Kit type
Bearing / seal service kit
Serviced gearbox reference
K5677-33104
Package scope
Listed parts only

Check before you order

Match the full mower deck model, machine configuration and serial number. Tractor model alone does not confirm fit. Select the bearing version and shim thickness required by the service manual; supplied alternatives and extras are not all installed together.

Additional bearings or oil seals shown in some listed gearbox versions but not supplied in this kit: 08101-06304. Compare the exact diagram before planning a complete overhaul.

F3710 applications with a supplied 05712-00728 feather key are limited to the serial range printed below. Later shafts use key K5684-33540, which is not included. F2510/F2510E versions specifying that key are not listed as direct fit.

Deck applications and version notes
  • RCK72P-28Z; 70712-33550 through 20115, K5687-33550 from 20116
  • RCK72P-F36; 70712-33550 through 16813, K5687-33550 from 16814
  • RCK72P-F36(F2680E/F3080); 70712-33550 through 16813, K5687-33550 from 16814
  • RCK72P-F36[F3680]; 70712-33550 through 16813, K5687-33550 from 16814
  • RCK72R-F36; 70712-33550 through 12128, K5687-33550 from 12129
  • RCK72R-F36(F2680E/F3080); 70712-33550 through 12128, K5687-33550 from 12129
  • RCK72R-F36(F3710) [catalog serial through 14543]; 05712-00728 through 14543
  • RCK72R-F36[F3680]; 70712-33550 through 12128, K5687-33550 from 12129
  • RCK72RP-1200Z
  • RCK72RP-1200Z(ZD1211RL-3) [catalog serial through 13091]; 05712-00728 through 13091
  • RCK72RP-1500Z(RL1611RLF) [catalog serial through 10317]; 05712-00728 through 10317
  • RCK72RP-1500Z(ZD1511RLF)
  • RCK72RP-1500Z(ZD1511RLF-3)
Supplied parts and quantities

Quantities are supplied parts, sets or packs as shown. Select shims to the service manual specification.

FLIP item OEM service reference Quantity supplied
703040 7C765-51260 1
703057 04612-00220 1
703064 70712-33570 1
703095 K5761-33540 1
703101 05712-00728 1
703118 76535-33440 1
703125 04611-00520 1
703163 08101-06205 1
703170 K5671-33342 1
703217 04015-50100 1
703224 01133-51025 1
703231 63313-32270 1
703248 36330-28410 2
706225 K5687-33550 1
706249 70712-33550 1

Before installation

Inspect reused parts and follow the exact equipment service manual for shim setup, torque and lubricant.

Searching with a code that has no dashes?

You can search our site with or without dashes — for example, RCK72P-28Z or RCK72P28Z. The codes below are alternate search formats for the models and service references already listed above. They do not add compatible models or supplied parts.

Deck model search codes: RCK72P28Z, RCK72PF36, RCK72RF36, RCK72RP1200Z, RCK72RP1500Z.

Part and gearbox reference search codes: 0113351025, 0401550100, 0461100520, 0461200220, 0571200728, 0810106205, 3633028410, 6331332270, 7071233550, 7071233570, 7653533440, 7C76551260, K567133342, K567733100, K567733103, K567733104, K567733105, K568733550, K576133540. Check the supplied-parts table to see what this kit includes.

Independent aftermarket product. Kubota names and numbers identify applications and service references; this is not a genuine Kubota product.

Aftermarket replacement part. Not affiliated with or endorsed by the original equipment manufacturer.

Product questions

Answers for this part.

Does this replace the complete gearbox?
Aftermarket gearbox bearing, seal and service hardware kit for the listed Kubota mower deck configurations. FLIP 707734. Gearbox family reference K5677-33104 identifies the serviced assembly; this kit does not replace that complete assembly. Match the full mower deck model, machine configuration and serial number before ordering. Tractor model alone does not establish fitment. This is a selective bearing, seal and hardware service kit containing only the parts and quantities listed below; it is not a complete gearbox assembly or every part needed for an overhaul. Select the bearing version and shim thickness specified by the service manual; supplied alternatives and extras are not all installed together.
Which mower decks does it service?
RCK72P-28Z; 70712-33550 through 20115, K5687-33550 from 20116; RCK72P-F36; 70712-33550 through 16813, K5687-33550 from 16814; RCK72P-F36(F2680E/F3080); 70712-33550 through 16813, K5687-33550 from 16814; RCK72P-F36[F3680]; 70712-33550 through 16813, K5687-33550 from 16814; RCK72R-F36; 70712-33550 through 12128, K5687-33550 from 12129; RCK72R-F36(F2680E/F3080); 70712-33550 through 12128, K5687-33550 from 12129; RCK72R-F36(F3710) [catalog serial through 14543]; 05712-00728 through 14543; RCK72R-F36[F3680]; 70712-33550 through 12128, K5687-33550 from 12129; RCK72RP-1200Z; RCK72RP-1200Z(ZD1211RL-3) [catalog serial through 13091]; 05712-00728 through 13091; RCK72RP-1500Z(RL1611RLF) [catalog serial through 10317]; 05712-00728 through 10317; RCK72RP-1500Z(ZD1511RLF); RCK72RP-1500Z(ZD1511RLF-3)
What parts and quantities are supplied?
7C765-51260 (FLIP 703040) x1; 04612-00220 (FLIP 703057) x1; 70712-33570 (FLIP 703064) x1; K5761-33540 (FLIP 703095) x1; 05712-00728 (FLIP 703101) x1; 76535-33440 (FLIP 703118) x1; 04611-00520 (FLIP 703125) x1; 08101-06205 (FLIP 703163) x1; K5671-33342 (FLIP 703170) x1; 04015-50100 (FLIP 703217) x1; 01133-51025 (FLIP 703224) x1; 63313-32270 (FLIP 703231) x1; 36330-28410 (FLIP 703248) x2; K5687-33550 (FLIP 706225) x1; 70712-33550 (FLIP 706249) x1
Are additional parts needed?
Additional bearings or oil seals shown in some listed gearbox versions but not supplied in this kit: 08101-06304. Compare the exact diagram before planning a complete overhaul. F3710 applications with a supplied 05712-00728 feather key are limited to the serial range printed below. Later shafts use key K5684-33540, which is not included. F2510/F2510E versions specifying that key are not listed as direct fit.

Parts for your repair

Other repair options

Choose the parts that suit your repair. Open each option to check its deck model and included parts.

Complete gearbox · FLIP 703033

Gearbox K5677-33104

Replace the gearbox as an assembly.

Check the listed deck model, shafts and mounting details. Add 80W gear oil before first use.

$ 1,249.23 · In stock

View part details →

Replacement gearset · FLIP 703439

Gearset K5763-33320

Replacement gears for the existing gearbox.

Match the gearset reference and full deck model on this listing.

$ 413.57 · Currently out of stock

View part details →

Customer reviews

Reviews for this part.

Read verified feedback, installation notes, and customer photos from this exact listing.

Before you order

Three details beat a hundred guesses.

Use the information on this page to verify the part before checkout.

1

Match the stamped number

Compare the OEM number, replacement number, or FLIP SKU shown above.

2

Confirm model and serial range

Check the model list and any serial number notes in the product details.

3

Get help when something is unclear

Share the model, serial number, and a photo. A Texas-based team member will help.
